Steel Strip Shear Welder Butt Fusion Welding Machine Tube Cutting Electrical Resistance Weld (ERW) Pipe Making Machine

• Overview
• Machine production range
• Production process flow
• Detailed Photos
• Our Advantages
• Our parterners
• Exhibition display
• Packaging & Shipping
• FAQ

Overview

Basic Info.

Model NO.	hf-0031
Pipe Material	Carbon Steel
Condition	New
Customized	Customized
Theory	Pulse
Application	Industry
Type	Pipe Welding Machine
Usage	Making Steel Pipe
Advantages	Roller Quickly Change in 10 Min
Cutting System	Cold or Hot Flying Saw
Control System	PLC (Imported Brand)
After Warranty Service	Video Technical Support, Online Support etc
Certification	CE, ISO, SGS
Round Pipe Diameter	4 mm to 273 mm
Round Pipe Wall Thickness	0.2 mm to 12 mm
Square/Rectangle Size	8*8 mm to 260*130 mm
Square/Rectangle Wall Thickness	0.25 mm to 11 mm
Useful Life	40 Years
Transport Package	Moulds: Packing in Wooden Case
Specification	customized
Trademark	st
Origin	Yangzhou China
HS Code	8515219100
Production Capacity	300 Sets Per Year

Packaging & Delivery

Package Size300.00cm * 200.00cm * 100.00cm Package Gross Weight200.000kg

Product Description

3. What are your payment terms? We support T/T, L/C, D/P, D/A, Western Union and so on. TT, 30% in advance, 70% balance before the shipment.

4. How long is the warranty period of your machine?

1 year .

Steel Strip Shear Welder Butt Fusion Welding Machine Tube Cutting Electrical Resistance Weld (ERW) Pipe Making Machine

Below is our standard series of our steel pipe making machine. Also we can provide you customized according to your specific request .

Machine production range

1. Are you manufacturer or trading company?

We are manufacturer with 30 years experience , Which is located in the base place of this industry Yangzhou city Jiangsu Province ,China . Welcome to visit our factory. 2. What shall we do if don't know how to operate your machine? We can dispatch our engineers to your country and you can also send your engineers to our factory for learning operation. Besides, there are detailed installation and operating instructions attached, We have telephone and email support at 24 hours per day.

Step 1: Un-coiler

Function: support rolled plate and strip tension for erw pipe mill production line, by the frame, main shaft, increases of drum, brake.

There are 3 types: pneumatic, hydraulic and manual.Step 2: Shear & butt-welding

Function: Shear the end of each strip coil, then welding them together, so that pipe making welding machine line can be continue production.

2 Types: Automatic & manual

Step 3: Vertical Accumulator

Function: storage strip to keep continue production for the machine to make metel tube.

Type: Vertical

Advantage: easy to operation, low investment. special for small size and light wall pipe

Disadvantage: less storage capacity, crease.

Step 4: Horizontal Accumulator

Function: storage strip to keep continue production for the Round Square Pipe Making Machine Production Line. Type: Horizontal Advantage: Large capacity. Disadvantage: more expensive than vertical type

Step 5: Forming section

Function: forming the tube from strip

Advantage:

>Advanced forming technical

>One-stage molding platform

>Reliable quality gear box

>Siemens Beide motor

Step 6: High Frequency Welding

Function: Welding the pipe , different thickness & diameter, the power of the HF welding machine welder

Step 7: Sizing section of pipe making machine

Function: sizing the tube to precise size Advantage: >Advanced sizing technical >One-stage molding platform >Reliable quality gear box and Siemens Beide motor >High precision, low error of the pipe size

Step 8: Flying saw

Function:cutting the tube mill line tube to right length.

Advantage: easy to operation, low investment.

Disadvantage: loud, cutting section generates burr.

Step 9: Cold saw cutting of erw tube mill line

Function:cutting the tube to right length. Advantage: No noise, no burr cutting precision and cross section . Disadvantage: the price is 4 times of ordinary flying saw.

Step 10: Run Out Table.

Function: run out the pipe, packing the pipe for tube making machine Type: Automatic or manualComplete Machine Composition

1.Un-coiler Function: support rolled plate and strip tension for erw pipe mill production line, by the frame, main shaft, increases of drum, brake.

2.Shear & butt-welding Function: Shear the end of each strip coil, then welding them together, so that pipe making welding machine line can be continue production.

3.Accumulator Function: storage strip to keep continue production for the machine to make metel tube.

4.Forming section Function: forming the tube from strip.

5.High Frequency Welding Function: Welding the pipe , different thickness & diameter, the power of the HF welding machine welder.

6.Sizing section of pipe making machine Function: sizing the tube to precise size.7.Flying saw Function:cutting the tube mill line tube to right length.

8.Run Out Table:Function: run out the pipe, packing the pipe for tube making machine.

ST company have successfully supplied world-class products and service to over 30 countries and areas around the world, such as: Poland, Spain, Russia, Yugoslavia, Ukraine, Turkey, Egypt, Saudi Arabia, India, Vietnam, Malaysia, Thailand, the Philippines, Pakistan, kazakhstan, Ethiopia, etc. in the past years.

Model	Diameter of welded pipe(mm)	Wall thickness of welded pipe(mm)	Speed of machine(m/min)	Power of main motor(k/w)	High-frequency power(kw)
HG16	8-25	0.25-1.0	30-100	30	60
HG25	8-32	0.35-1.3	30-100	45	100
HG32	13-50.8	0.5-2.0	30-90	110	150
HG50	20-63.5	0.6-2.5	30-90	160	200
HG60	25-63.5	0.8-3.0	20-80	185	250
HG76	25-80	1.2-4.0	20-70	200	300
HG90	32-90	1.5-4.5	20-60	110*2	400
HG115	38-115	2.0-5.0	20-60	160*2	400
HG165	80-165	2.0-6.0	15-50	200*2	500
HG219	90-219	3.0-8.0	15-50	250*2	600
HG273	165-355	4.0-10.0	15-40	250*1 /185*2	800
HG300	165-355	4.0-12.0	15-30	250*2/200*2	1200
