Overview

Basic Info.

Model NO.	TK-6035T
Application	Home Appliance, Environmental Equipment, Petroleum Machinery Manufacturing, Agriculture Machinery, Food Machinery, Automotive Industry, Shoemaking Industry, Woodwork Industry, Advertising Industry
Cooling System	Water Cooling
Technical Class	Continuous Wave Laser
Applicable Material	Metal
Structure Type	Desktop
Laser Classification	Solid Laser
Laser Technology	Laser Flame Cutting
X\Y Max. Moving Speed	120 M/Min
X\Y Max.Cutting Speed	60m/Min
Linear Rail Diameter	25mm
Helical Rack Diameter	25mm
Acceleration	1.2g
Positioning Accuracy	0.05mm/M
Repeated Positioning Accuracy	0.03mm
Controller	Controller
Fiber Laser Source	Original Max or Raycus
Laser Cutting Head	Raytools
Lathe Bed	Toptek Lathe Structure
Gear Reducer	France Motovario
Water Chiller	S&a
Transport Package	Metal Frame
Specification	8700*1200*1800mm
Trademark	TOPTEK LASER
Origin	China
HS Code	845611
Production Capacity	100/Week/PC

Packaging & Delivery

Package Size490.00cm * 230.00cm * 200.00cm Package Gross Weight3000.000kg

Product Description

Machine designThe whole design adopts split design, which is safe and environmentally friendly and easy to maintain;With partition dust removal function, the dust removal protection design is more rigorous and reasonable, and the effect of exhausting dust removal is increased;Automatic lubrication system upgrade, increase gear and screw lubrication, provide lubrication at egular intervals,ensure normal operation of equipment, and extend equipment service life;The follow-up system and the automatic seeking system are upgraded to improve the cutting effect and efficiency

TOPTEK Laser is an innovative high-tech manufacturer specializing in Intelligent Laser Solutoins (Laser automatic prodution line, Laser welding, Laser cutting, Laser cleaning, 3D Automation welding, Robot Automation station, Laser marking ). Our mission is to provide Reliable Industrial Solutions to make your production smarter, faster and more cost-efficient with minimum human labor required. After 10+ years development, TOPTEK are supporting 10,000+ global parnters in customiztion, marketing, local service to enhance their international competitiveness

TOPTEK Philosophy 1. International Vision 2. Altruistic Thinking 3. Reliable Action

What we support ? 1. Customized technical solutions (OEM, ODM) 2. Reliable service timely, 3. Strong marketing (Online/Offline) 4. Lifetime service and upgrade 5. Financing 6. Demo and spare parts stocks

Q1. When did your factory establish? A1.We start to focus on CNC laser equipment since 2008, mainly focus on fiber laser cutting/welding machine and cutting/welding robot etc. Welcome to visit us.Q2. What about machine warranty? A2:2-year warranty, If the main parts are damaged by non-human factors, they can be replaced free of charge. You can choose to replace them at the local after-sales point or send them for repairQ3. How to install and use? A3.We provide 24-hour online service. You can install according to the machine's operation manual and installation video, or choose door-to-door installation service.Q4. What about after-sales problems? A4.Please contact us. We will assign you after-sales personnel in the corresponding language according to your country and region. You can directly describe your problem with the after-sales personnel. Replacement and maintenance within the scope of warranty are free of chargeQ5. What about wholesale price? A5:If you are a wholesaler, distributor or agent, please contact us to obtain the wholesale price.

For more detailed information, please contact us






























Product Description

Features and advantages:1.High-quality national standard Q235: the main body of the bed, full spot welding2.Heat treatment process: high temperature annealing, high strength, high toughness3.Precision machining: rough machining,semi-finishing,vibration failure, finishing, eliminating welding stress and machining stress4.Design features: brief introduction to structural design, small error and high precision5.Stress balance: structural optimization and upgrading,and more reasonable structural support6 Process to ensure product accuracy

Lifting roller system The supporting mechanism adopts the cylinder to move up and down, the left and right waist holes of the cylinder mounting plate, and the center can be adjusted.The variable diameter wheel is installed with a waist hole,and the angle can be fine-tunedFeatures and advantages:The variable diameter wheel adopts the integral injection molding process, which has high precision, light weight and small friction coefficient;The cylinder support is stable and does not swing, and the cutting accuracy is higher;Easy to adjust, suitable for pipes with different

Chuck systemThe chuck is a full-stroke pneumatic chuck with a built-in cylinder, which is easy to install, and the clamping and loosening action is realized by the side air intake. It can clamp a full range of applicable pipe fittings, and the full stroke improves production efficiency.Features and advantages:Easy installation, high applicability of pipe fitting types, full stroke, high efficiency;Good gear meshing performance, high degree of coincidence, small stress and long service life;High stability, self-centering and high precision;

MAX Laser SourceSmall size, light weight, easy to integrate.The cutting speed is greatly improved.Low energy consumption.Suitable for different fields of application.Safety protection meets European standards. lGlobal maintenance services.

S&A Industrial chillerChina TOP 2 brandDual temperature dual control industrial chiller lHigh efficiency, lower noise performance.Turbine flow standard switch can be used to control the temperature of the laser cooling water.

FSCUT laser cutting systemFSCUT laser cutting control system is a high-performance open-loop laser control system independently developed by Shanghai Bochu Electronic Technology Co., Ltd. Widely used in the field of metal and non-metal laser cutting. Due to its outstanding performance in the field of medium-power fiber laser cutting, it has been favored by the majority of high-end users.

YASKAWA servo motor and driversServo system ensures the possibility of realizing extremeprecise positioning with the excellent dynamic response acceleration property and closed loop control method, mechanism operate smoothly, reliably and free ofmaintenance;location accuracy: ≤±0.04mm

Taiwan HIWIN linear square guide railStable and reliable high-speed operation.Lower noise volume, ensuring high precision and long service life.

No.	Main parts	Quantity	Brand
1	Fiber laser source	1 set	Original MAX or Raycus
2	Laser cutting head	1 set	Raytools
3	Lathe bed	1 set	TOPTEK lathe Structure
4	Gear reducer	3 sets	France Motovario
5	Water chiller	1 unit	S&A
6	X\Y servo system	1 unit	YASKAWA
7	Z servo system	1 unit	YASKAWA
8	X\Y rack	1 set	Taiwan YYC (Grinding class)
9	X\Y linear rail	1 set	Taiwan HIWIN
10	Pneumatic Components	Several	Japan SMC high-pressure proportion valve
11	Electrics	Several	TOPTEK
	Controller	1 set	CypCut (FSCUT3000S )
13	Auto-height-adjusting system	1 set	CypCut
14	Auto-lubrication system	1 set	TOPTEK
15	Industrial computer	1 set	TOPTEK
16	Exhaust fan	1 set	TOPTEK

Model	TK-6012T		TK-6016T		TK-6022T		TK-6025T		TK-6035T		TK-6045T
Working area(mm)	6000*120		6000*160		6000*220		6000*250		6000*350		6000*450
Positioning accuracy	±0.03mm/m
Repeated positioning accuracy	±0.02mm/m
Acceleration	1.2G
Diameter of tube	120mm	160mm		220mm		250mm		350mm		450mm
Power	3.0KW;6.0KW;12KW;20KW;
Options	BEVEL cutting head, Auto-loading system
